Product Details:
Payment & Shipping Terms:
|
| Pressure: | 1.5Mpa | Usage: | Corrosive, Inorganic Materials |
|---|---|---|---|
| Fuel: | Diesel, Electric | Flow Rate: | 18000~28000 L/h |
| Warranty: | 12 Months | Product Name: | Industrial Peristaltic Pump |
| Capacity: | 0.3-50m3/h | Material: | Stainless Steel 304,aatural Rubber Hose |
| High Light: | squeeze mortar pump,peristaltic cement pump |
||
Sincola SH series industrial hose pump is a kind of peristaltic pump, which is suitable for handing aggressive, high viscosity, high density products, such as abrasive slurries, corrosice acids, gaseous liquid, sand/cement mortar, etc. Also is used for dosing pump with 1% repeat precision.
1. No valve operation, no back flow, stable pumping flow, low fault rate.
2. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.
3. High vacuum, strong self-suction capacity.
4. Convenient maintenance, less wearable parts (except extruded hose).
| Model | KH76C Industrial Peristaltic Pump |
| Output | 18000~28000 L/h |
| Rated pressure | 1.0 MPa |
| Rev. | 40~55 r/min |
| Hose length | 1900 mm |
| Max. particle dia. | 6 mm |
| Max. suction dist. | 5 m |
| Motor power | 11.0/ 15.0 KW |
| Reducer type | Gear reducer |
1. Architecture: mortar, plaster, cement paste, soil slurry, silt slurry, lime slurry, foamed concrete, architectural coating, refractory, accelerator, waste water, sewage and so on.
2. Chemical: corrosive, acid, alkali, phosphate liquid, inorganic materials, crystalline liquid, suspending liquid, emulsion, resin, electroplate liquid, electrolyte solution, precipitate.
3. Agriculture: phosphate fertilizer, compound fertilizers, thick slurry, precipitated sludge.
Peristaltic Pump Tubing Advantages:
1. Unique structure with no sealing element, no leakage, no pollution;
2. Advanced rolling technology adopted, no need of roller;
3. High suction ability, self-cleaning ability, sucking materials in two directions;
4. Simple hose installation, simple operation, easy to assemble and maintain, lower maintenance cost;
5. Linear regulation of flow rate,limited,measuring ability;
6. No block when pumping fluid with high viscosity and foreign substance contained;
7. Long service life;
8. High lift and output pressure.
Application:
Mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
Company Introduction
Sincola has been engaged in the research and production of hose pump for many years. With the experiences and special technology SINCOLA won a quick development on the hose pump int the recent years.
Today SINCOLA hose pumps are the very mature products wiwth different kinds of types. The work pressure can reach 1.5Mpa and the output can be 40 cubic meters/hour. SINCOLA pumps are widely applied at home and abroad. Based on the excellent work principle, SINCOLA hose pumps will have a more extensive application in the next days.
If you need more informations, please contact with me.
