Product Details:
Payment & Shipping Terms:
|
| Condition: | New | After-sales Service Provided: | Video Technical Support |
|---|---|---|---|
| Product Name: | Concrete Pump | Application: | Concrete Transfer |
| Max Aggregate Size: | 30mm | Concrete Pump: | Pumping Concrete Machine |
| High Light: | high pressure concrete pump,hydraulic concrete mixer |
||
Description
1. Portable concrete pumps are a kind of mortar conveying equipments, specially designed for the floor heating projects according to its characteristics. They are extensively applied in the large-area and highly effective construction of fine stone concrete or mortar stuffing in floor heating projects.
2. It's also widely used for the conveying of fine stone concrete, fire-resistant and heat-insulating materials in various of construction projects; the conveying of afforesting soil in Eco-environment construction and the pressure grouting various of basic piles.
3. The inner diameter of conveying pipe has increased into Ø100 based on Ø80 so that concrete pump can convey concrete with diameter no more than 30mm, which makes it has a broader applicaitons, such as the conveying of mortar, small stones and large aggregate concrete.
Parameter
| Diesel Engine mini concerete pump | |
| Specifications | SHBT90 |
| Conveying capacity(low pressure) | 90m³/h |
| Conveying capacity(high pressure) | 61m³/h |
| Conveying pressure(low pressure) | 8Mpa |
| Conveying pressure(high pressure) | 11.8Mpa |
| Hydraulic system pressure | 32Mpa |
| Switch of high and low pressure | auto |
| Fuel tank capacity | 190ml |
| Power | 140KW |
| Rotary Speed | 2200 r/min |
| Hopper Volume | 0.6 m³ |
| Hydraulic Oil tank volume | 600 L |
| Conveying distance | (φ125)m |
| Horizantl/Vertical | 860/200 |
| Diameter of Cylinder without bore | 125 mm |
| Diameter of Cylinder bore | 80 mm |
| Diameter of Concrete cylinder | 230 mm |
| Cylinder push distance | 1600 mm |
Feature
Compact structure, easily moved, highly movable and flexible; Intelligent power control system with PLC for safe, smooth and efficient operation; Plunger pump with constant power, ensuring the efficiency of main engine; Equipped with wire remote controller easy to operate; High performance sealing of S pipe valve installed with floating wear resistant; High delivery pressure to meet demand of high building and long distance projects; Low cost maintenance, beautiful appearances.
