Payment & Shipping Terms:
|Condition:||New||After-sales Service Provided:||Video Technical Support|
|Product Name:||Concrete Pump||Application:||Concrete Transfer|
|Max Aggregate Size:||30mm||Concrete Pump:||Pumping Concrete Machine|
high pressure concrete pump,
hydraulic concrete mixer
This fine stone concrete pump is a machine for transporting freshly prepared mortar for plastering and masonry work through pipes or hoses to various points at a work site; the mechanism is based on the suction and pressurization of the mortar. A distinction is made between pumps with diaphragms and those without diaphragms, depending on the action of the plunger.
1. Biggest characteristic is the Electric Concrete Trailer Pump, mobile flexibility, mobility strong, suitable site turns alternating operations and in the process of mixing and pumping, originally required the two programs you only need one operator to complete, save manpower.
2. Car-forced mixing pump is a very high degree of automation of machinery and equipment, set automatic feeding, mixing, high pressure pump with one, can save a lot of labor to build houses, in line with the current development situation of labor.
1. Use S-Valve To Switch The Direction, For Cement Mortar, Fine Stone Concrete Conveying.
2. Good Sealing S-Valve, Installed With Floating Wear Resistant Ring.
3. High-Quality Wear Resistant Alloy Components For Long Service-Life.
4. High Delivery Pressure For Demand Of High-Rise And Long Distance Projects.
5. Use The Kawasika Main Oil Pump, Double-Loop Open Circuit Hydraulic System, Ensure Fast Direction Switching Speed And High Efficiency.
6. Air Cooling System, Without Dependence Of External Water Supply.
7. With Re-Pumping Function To Smooth Construction Of Better Accessibility.
8. Automatic Lubrication System For Long Service-Life.
9. PIC System To Ensure Best Electrical Control Performance.
10. Equipped With Wired Or Wireless Remote Controller, Easy To Operate.
|Diesel Engine mini concerete pump|
|Conveying capacity(low pressure)||90m³/h|
|Conveying capacity(high pressure)||61m³/h|
|Conveying pressure(low pressure)||8Mpa|
|Conveying pressure(high pressure)||11.8Mpa|
|Hydraulic system pressure||32Mpa|
|Switch of high and low pressure||auto|
|Fuel tank capacity||190ml|
|Rotary Speed||2200 r/min|
|Hopper Volume||0.6 m³|
|Hydraulic Oil tank volume||600 L|
|Diameter of Cylinder without bore||125 mm|
|Diameter of Cylinder bore||80 mm|
|Diameter of Concrete cylinder||230 mm|
|Cylinder push distance||1600 mm|
